INTRODUCTIONS
Shanghai Electric Gotion New Energy Technology Co., Ltd., a joint venture between Shanghai Electric Group Co., ltd. and Guoxuan High-tech Co., Ltd. which is established in December 2017. Shanghai Electric Group Co., Ltd. amount to 51% of the total registered capital which is 300 million yuan, while Hefei Gotion High-tech Power Energy Co., Ltd. amount to the rest 49%.
The project owns an annual output of 10GWh lithium-ion battery energy storage system production base, which is jointly constructed by Shanghai Electric and Gotion Hi-Tech in two phases. It covers an area of 294,668 square meters and the total construction area is about 280,000 square meters. The first phase of the project has built a 5GWh energy storage battery system product line, which has been put into operation in the second quarter of 2020. It is the most advanced and largest lithium-ion battery energy storage system industrial base in the east of China .
Features:
- Brand Guoxuan-----Gotion
- Cell type: LiFePo4 cells
- Capacity: 102 Ah
- Options 99% Efficiency
- Application: Solar energy storage system
- Environmentally Friendly & Lead Free Stress-Free
- Battery Bank Expansion Capacity Longer Lasting;
- Part NO.: 102-IFP50160116A-102Ah
Detail Descriptions
Large Capacity LFP Cell 3.2V 102Ah Guoxuan Lithium Iron Phosphate Batteries - the ideal solution for your energy storage needs! As a leading producer of lithium iron phosphate batteries, Guoxuan is committed to providing high-quality and reliable products that meet the unique requirements of each customer.
With a capacity of 102Ah and a voltage of 3.2V, these LFP cells are designed to deliver long-lasting performance and reliability. Whether you're using them for your home energy storage system, electric vehicle, or industrial application, these batteries provide a dependable and sustainable energy source.
The advanced lithium iron phosphate technology used in these batteries ensures that they have a longer lifespan and are more durable than traditional lead-acid batteries. This means that you can enjoy years of reliable performance without having to worry about costly maintenance or replacements.
the Large Capacity LFP Cell 3.2V 102Ah Guoxuan Lithium Iron Phosphate Batteries are designed to be lightweight, compact, and easy to install. They also have a high discharge rate, which makes them ideal for high-power applications.
So whether you're looking to power your home or business with clean and renewable energy or need a reliable power source for your electric vehicle, the Large Capacity LFP Cell 3.2V 102Ah Guoxuan Lithium Iron Phosphate Batteries are the ideal solution. Contact Guoxuan today to learn more about their custom OEM services and support options.
Coremax wholesale guoxuan 102ah with Full-capacity battery, 100% quality test, guaranteed to meet customer needs. This 3.2 volt lfp cells with Long cycle life and high energy density.As Factory direct supply chain. Coremax providel wholes low price for bulk quantity and fast leadtime.
3 YEAR WARRANTY
Factory directly supply, world beating, best in class, OEM manufacturer defect warranty.
SIZE
102-IFP50160116A-102Ah. 50*160*116MM. Replaces most bateria battery and many lithium ion, LiFePo4 or Lead acid batteries.
WEIGHT
2.2kg
CAPACITY
102Ah (102 ampere hours). CMX Lithium batteries provide consistent power for all 100 amp hours. CMX LiFePO4 batteries have a flat voltage curve, which means they have a steady power output as the battery discharges. The power output will not dramatically drop like similar sized SLA batteries. You get all the juice down to the last drop.
LIFECYCLES (BATTERY LIFESPAN)
Up to 80% capacity for 3,000 cycles in recommended conditions. The typical SLA has 500 cycles. Dakota Lithium batteries last so long that the price per use is a fraction of traditional batteries.
OPERATING TEMPERATURE
Ideal for rugged & harsh environments. Much better than SLA or other lithium’s. -20'F min, +120'F max optimal operating temps (battery performs well down to -20'F). Avoid charging below 32'F.
3 YEAR WARRANTY
Factory directly supply, world beating, best in class, OEM manufacturer defect warranty.
SIZE
102-IFP50160116A-102Ah. 50*160*116MM. Replaces most bateria battery and many lithium ion, LiFePo4 or Lead acid batteries.
WEIGHT
2.2kg
CAPACITY
102Ah (102 ampere hours). CMX Lithium batteries provide consistent power for all 100 amp hours. CMX LiFePO4 batteries have a flat voltage curve, which means they have a steady power output as the battery discharges. The power output will not dramatically drop like similar sized SLA batteries. You get all the juice down to the last drop.
LIFECYCLES (BATTERY LIFESPAN)
Up to 80% capacity for 3,000 cycles in recommended conditions. The typical SLA has 500 cycles. Dakota Lithium batteries last so long that the price per use is a fraction of traditional batteries.
OPERATING TEMPERATURE
Ideal for rugged & harsh environments. Much better than SLA or other lithium’s. -20'F min, +120'F max optimal operating temps (battery performs well down to -20'F). Avoid charging below 32'F.
COREMAX Manufactured with the highest quality components and the customers safety in mind, this battery contains a battery management system (BMS). BMS provides all kinds of protection for the battery and customer, equipped with Over charge and short circuit protection. This IFP27175200A-105A grade A cell suitable for any Off/on grid solar energy systems, RV, Camping, Backup power systems and much more.
No matter use it for in series or parallel connection Make sure to only use a compatible lithium charger for this battery and tightly screw the terminals. Having loose terminals will cause a buildup of heat resulting in damage to the battery.
Specifications
Project | Specification | |||
---|---|---|---|---|
Brand | GuoXuan 102-IFP50160116A-102Ah | |||
Size | 50*160*116MM | |||
Weight | (2060±50g) | |||
Nominal voltage | 3.2V | |||
Ac internal resistance | (0.4~0.7)mΩ | |||
DC internal resistance | ≤1.5mΩ | |||
Rated capacity | 105AH | |||
Working voltage | 2.0V~3.65V | |||
Energy density | 163Wh/kg | |||
Maximum continuous charging current | 0.1C、0.5C、1.0C、2.0C | |||
Maximum allowable charging voltage | 3.9V | |||
Maximum allowable charging temperature | 0℃~55℃ | |||
Maximum continuous discharge current | 2C | |||
Maximum pulse discharge current | 5C(10S) | |||
Maximum discharge power | 2500W | |||
Maximum feedback power | 1400W | |||
Standard cycle life | ≥3000 time(25℃,1C) | |||
Optimum storage temperature range | 10℃~30℃ | |||
self-discharge | ≤4% |
Features of COREMAX Lithium-ion Deep Cycle Batteries:
Light weight, up to 80% less than a conventional, comparable energy storage lead-acid battery.
Lasts 300-400% longer than lead-acid.
Lower shelf discharge rate (2% vs. 5-8% /month).
Drop-in replacement for your OEM battery.
Expected 8-10 years of battery life.
No explosive gasses during charging, no acid spills.
Environmentally friendly, no lead or heavy metals.
Safe to operate!
The term “Lithium-ion” battery is a general term. There are many different chemistries for Lithium-Ion batteries including LiCoO2 (cylindrical cell), LiPo, and LiFePO4 (cylindrical/prismatic cell). COREMAX mostly focuses on designing, manufacturing and marketing LiFePO4 batteries for its starter and deep cycle batteries.
What are LiFePO4 (Lithium Iron Phosphate) Batteries?
Lithium Iron Phosphate (LiFePO4) batteries provide several advantages over traditional Lithium-ion batteries based on LiCoO2 chemistry. LiFePO4 batteries provide much higher specific capacity, superior thermal and chemical stability, enhance safety, improve cost performance, enhanced charge and discharge rates, enhanced cycle life and come in a compact, lightweight package. LiFePO4 batteries an offer a cycle life of over 2,000 charge cycles!
Notice
- Only charge with recommended LiFePo4 battery charger with CC/CV charging profile and 14.6V max 100A voltage.
- Always use a suitable fuse between the battery and trolling motor to protect both, Use battery cables of sufficient thickness with M8 tongue connectors (or ANEN plug connectors) to connect your trolling motor for a safe and reliable connection. Never use crocodile clamps to connect to the battery! These connections are not safe and can result in heat development and damage to your trolling engine and battery. Damage caused by unsuitable connectors or cabling is explicitly excluded from our warranty terms.
- This battery is not suitable for use with caravan movers! The high peak currents can cause irreversible damage to your battery.
- Batteries can be connected in parallel for increased capacity. Always ensure that batteries are of same type, age, and charge status before connecting and use cables of sufficient thickness!
- Our batteries are splash-water proof according to the IP54 standard. They cannot be fully immersed in water or handle heavy rains. To avoid problems use a waterproof battery container or battery bag and position the battery upright on a slightly elevated level so that it is not continuously standing in the water, or water can enter via the top of the battery. Water damage is explicitly excluded from our warranty terms.




COREMAX provide custom OEM service for different brand. Please feel free to contact us. We hope to help more brands like rebelcell bateria to build high quality brand
FAQ
Welcome to contact the Online Services. If it’s not our working time, please click “Send Inquiry” above or “Leave a Comment” below, We will offer you the best quote in 24 hours after we get the product specifications such as voltage capacity application etc.
We advice to get samples and evaluate in advance before bulk order. We will make the bulk order exactly the same as you request.
It depends on your order quantity.Normally 1-2days if we have sample in stock, 5-7days for newly produced samples.10-20 day for big order.
By Express (3-7 working days), suitable for urgent time or small quantity. By Sea (15-30 days), it suitable for mass production. By Air (4-7 days), from airport to airport.
