16s 100a balance bms with CAN RS485 for lifepo4 3.2volt battery 16 series smart bms

Name: 16s 100a balance bms with CAN RS485 for lifepo4 3.2volt battery 16 series smart bms
Brand: BYD CELL
SKU: 16S CAN BMS
Price: 95.00 USD
Availability: InStock

This 16S 16 series BMS is design for server rack battery or powerwall lifepo4 lithium batteries. BMS built in Blance function and communication rs485 CAN port. In additional, It has RS232 and DRY contact function to control other functions. This 16 series BMS use for different brand batteries from China. Like most some popular brand gsl, bsl battery, meritsunpower,genixenergy, gyll, jakiper battery, trophy battery, must ess, sok battery, signature solar, ufo, gso,sako,taico, seplos and youth power( please confirm with your supplier for detail BMS specification if you cooperate with above brands). This pace BMS is design for 16S LiFePO4 batteries. However, you can use it for 15S 48volt. It is engineered to deliver superior performance. excellent compatibility, control with precision, and untethered protection that ensure your power sources stay in perfect condition and make sure they perform to the fullest.

Coremax provide Wholesale China Lithium ion and LiFePo4 ESS Powerwall BMS PCB board for battery pack manufacturer or DIY user.

Compare

Add to wishlist

SKU: 16S CAN BMS Category: Solar System accessories

Description

Basic Specifications

16S or 15S LiFePo4 battery packs for solar
100A charge and discharge current
30A charging limit PCB built in
Precharge function resistor built in
Communicate with inverter by rs485/CAN
Support 16 pcs connect in parallel max
Wall mount battery or server rack battery
Bulk quantity support battery pack factory

This 16S 48V /51.2v BMS is design for solar energy storage systems. The BMS use for different brand batteries from China. and possible communicate with different inverters by RS485 or CAN. Additional the BMS can connecte with computer software monitor. Like most some popular brand gsl, bsl battery, meritsunpower,genixenergy, gyll, jakiper battery, trophy battery, must ess, sok battery, signature solar, ufo, gso,sako,taico, seplos and youth power( please confirm with your supplier for detail BMS specification if you cooperate with above brands). This pace BMS is design for 16S LiFePO4 batteries. However, you can use it for 15S 48volt. It is engineered to deliver superior performance. excellent compatibility, control with precision, and untethered protection that ensure your power sources stay in perfect condition and make sure they perform to the fullest.

Solar energy BMS for Server rack Battery or powerwall system.

The 16 series BMS is widely used in lithium iron phosphate batteries for their efficient power balancing, over-discharge, over current, and short circuit protection. Our Battery Management System 48V is compatible with locomotion applications i.e.; wind energy storage systems, home energy storage systems, UPS backup power, communication base station power, emergency equipment, and DIY batteries, etc.

Detail Specifications

Item		Unit	Module Specification	Remark
Nominal Capacity		Ah	100Ah @ 0.5C
Actual Capacity		Ah	≥105Ah @ 0.5C
Configuration		-	16S1P
Operating Temp.	Min.	℃	0 (Charge).-20 (Discharge)	@ Temp Sensor
Operating Temp.	Max.	℃	55	@ Temp Sensor
Storage Temp.	Min.	℃	-20
Storage Temp.	Max.	℃	55
Nominal Voltage		V	51.2	Cell 3.2V
Max. Voltage		V	58.4	Cell 3.65V
Min. Voltage		V	40	Cell 2.5V
Nominal Energy Content		kWh	≥ 5kwh @ 0.5C
Weight		Kg	≤48
Resistance Consistency (10s, 25℃, 30%SOC, BOL)		-	-15%/+10% DC-IR
Discharge Operation max current (10s, 25℃, SOC50%, BOL)		A	100Amps	120 Per 1 module
Charge Operation max current (10s, 25℃, SOC 50% BOL)		A	100 A	90Per 1 module
Continuous Discharge Operation current (25℃, SOC50%, BOL)		A	50A	105 Per 1 module
Continuous Charge Operation current (25℃, SOC 50% BOL)		A	50 A	52.5 Per 1 module
Standard Charge (@ 25℃ )		-	Constant Current: ≤0.5C Constant Voltage:3.65V End Condition(Cut off): ≥0.02C
The state of charge(SOC) of the module		-	SOC 30%±3%	before shipping
Self Discharge Rate(SOC 100%, 25℃ , Loss/Month， @BOL)		%	Max 3
Safety and Reliability		-	Compliance with QC/T 743 test standard	GBT Certificate @cell
Insulation		MΩ	Min 20MΩ/1000VDC, 25℃±5℃, RH50%
Cooling type		-	Natural(Passive) Convection	(Air Cooling)

Power Balancing:

Power balancing 2.65V
Balance release volt 2.65V
Balance current 40±5mA

Over discharge protection:

Over discharge detect volt 2.8±0.05V
Over discharge detect delay 0.5V
Over discharge volt release 3.0±0.05V

Over current protection:

Over current detect volt 150mV
Over current detect delay 9MS
Over current protection Can be customized

Short circuit protection:

Short circuit protection; External load short circuit
Short circuit detect delay 250uS
Short circuit detect release; Disconnect load

Resistance: Main circuit resistor ≤10mΩ

Self-consumption: Working current ≤100uA

Sleepy current: (When over-discharged) ≤20uA

Working temp: Temp range -20/+80ºC

Computer Monitor

Computer monitor software allows you connect battery BMS via RS485 or CAN. Check the real working condition. These include battery cell voltage, temp of the battery and environment and MOS of the BMS. Charging or discharging current. And also all settings of over charge, over discharge , over current, over or low temp protections.

APPLICATIONS

Battery backup – A simple, robust option for using clean energy to keep a building powered during power outage. lithium ion powerwall 100 amp hour 48 volt suitable for single use or in parallal.
Self-supply – Obtain energy from Solar panels or AC grid, and work independence by storing excess solar energy for later use
Time-of-Use – Store off-peak grid power for use when utilities charge the highest rates.
Demand charge curtailment – Reduce the demand charge for businesses
Off-grid – Use renewable house hold lifepo4 battery for solar storage energy to power your home during the day light, and stored excess energy for the night.

“CMX 48v 100ah lifepo4 battery for solar storage eliminated the most difficult challenges we face when building microgrids in remote tropical locations. The batteries are much easier to transport and they have a good chance of lasting the entire 20 years. This means CMX batteries generally pay for themselves in under 4 years!”

The tesla powerwall alternative from CMX is one of the best source I got from China. This powerwall with 5 kwh energy. When I use 2pcs for the small system works perfectly with my growatt 5000w inverter. Our customer love this Coremax powerwall so much and most important it can really last.

This is a perfect lithium 48v 100ah battery powerwall I have ever got from China. CMX use laser welding for these prismatic lfp cells and the BMS can communicate with my sol art 8000w and 12000w inverter. it shows all information. thanks guys. a cheaper alternative to tesla powerwall.

PDF Datasheet

Distributor Price Inquiry

Additional information

Weight	1 kg
Dimensions	30 × 10 × 5 cm
Cell Brand	BYD CELL, CATL, EVE CELL, Gotion, Lishen, svolt battery

Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “16s 100a balance bms with CAN RS485 for lifepo4 3.2volt battery 16 series smart bms”

About brand

BYD is a leading Chinese manufacturer of lithium-ion batteries, including LiFePo4 (lithium iron phosphate) battery cells. BYD's LiFePo4 battery cells are known for their excellent safety, durability, and high energy density, making them a popular choice for a wide range of applications, including electric vehicles, energy storage systems, and more. One of the key benefits of BYD's LiFePo4 battery cells is their safety. Unlike other types of lithium-ion batteries, such as lithium cobalt oxide, LiFePo4 batteries are much less prone to overheating or catching fire. This is because LiFePo4 batteries have a more stable chemical structure that is less likely to break down or react with other materials. Another advantage of BYD's LiFePo4 battery cells is their durability. These battery cells can withstand a large number of charge and discharge cycles without significantly degrading their performance or lifespan. This makes them ideal for use in energy storage systems and other applications that require long-term reliability. BYD's LiFePo4 battery cells also have a high energy density, meaning they can store a large amount of energy in a relatively small space. This makes them well-suited for use in electric vehicles and other applications where space is limited. Overall, BYD's LiFePo4 battery cells are a reliable and safe choice for a wide range of applications, from electric vehicles to energy storage systems. Their durability, high energy density, and safety make them a popular choice among consumers and manufacturers alike.CATL (Contemporary Amperex Technology Co. Limited) is a Chinese manufacturer of lithium-ion batteries, including batteries for electric vehicles and energy storage systems. CATL is known for its high-quality products and is one of the largest battery manufacturers in the world. One of the key advantages of CATL batteries is their high energy density. This means that CATL batteries can store a large amount of energy in a relatively small space, making them ideal for use in electric vehicles and other applications where space is limited. CATL batteries also have a long lifespan, meaning they can be charged and discharged many times without significantly degrading their performance. This makes them a popular choice for energy storage systems, which need to be reliable over the long term. Another advantage of CATL batteries is their fast charging capability. CATL's battery technology enables rapid charging, which is critical for electric vehicles that need to be recharged quickly to minimize downtime. In addition to their technical advantages, CATL batteries are also produced with a focus on environmental sustainability. CATL uses renewable energy sources such as solar and wind power to produce its batteries, and it also uses recycled materials in its manufacturing process. Overall, CATL batteries are a reliable, high-performance choice for a wide range of applications, from electric vehicles to energy storage systems. Their high energy density, long lifespan, and fast charging capability make them an excellent option for manufacturers and consumers alike who prioritize performance and sustainability.EVE Energy Co., Ltd. is a leading Chinese manufacturer of lithium-ion batteries, including lithium iron phosphate (LiFePO4) batteries, which are commonly used in electric vehicles and energy storage systems. EVE lithium battery cells are known for their high energy density and long lifespan. The high energy density means that the batteries can store a large amount of energy in a relatively small space, which is ideal for applications where space is limited. The long lifespan means that the batteries can be charged and discharged many times without significantly degrading their performance, making them a popular choice for energy storage systems. EVE's lithium battery cells are also designed with safety in mind. The company uses advanced manufacturing processes and materials to ensure that their batteries are safe and reliable, and they have passed rigorous safety tests and certifications. EVE offers a range of lithium battery cell products to meet different needs and applications. Their products include cylindrical and prismatic cells, with capacities ranging from 10Ah to 500Ah. EVE's products are widely used in a variety of applications, including electric vehicles, energy storage systems, and backup power systems. In addition to their technical advantages, EVE's lithium battery cells are also produced with a focus on sustainability. The company uses renewable energy sources such as solar and wind power in its manufacturing process, and it also uses recycled materials to reduce waste. Overall, EVE's lithium battery cells are a reliable, high-performance choice for a range of applications. Their high energy density, long lifespan, and focus on safety and sustainability make them an excellent option for manufacturers and consumers alike who prioritize performance, safety, and environmental responsibility.Gotion High-Tech Co., Ltd. is a Chinese manufacturer of lithium-ion battery cells, including lithium iron phosphate (LiFePO4) batteries, which are commonly used in electric vehicles, energy storage systems, and other applications. Gotion lithium battery cells are known for their high energy density, long lifespan, and fast charging capabilities. The high energy density means that the batteries can store a large amount of energy in a relatively small space, which is ideal for applications where space is limited. The long lifespan means that the batteries can be charged and discharged many times without significantly degrading their performance, making them a popular choice for energy storage systems. The fast charging capabilities enable the batteries to be charged quickly, reducing downtime and increasing efficiency. Gotion's lithium battery cells are also designed with safety in mind. The company uses advanced manufacturing processes and materials to ensure that their batteries are safe and reliable, and they have passed rigorous safety tests and certifications. Gotion offers a range of lithium battery cell products to meet different needs and applications. Their products include cylindrical and prismatic cells, with capacities ranging from 20Ah to 300Ah. Gotion's products are widely used in a variety of applications, including electric vehicles, energy storage systems, and backup power systems. In addition to their technical advantages, Gotion's lithium battery cells are also produced with a focus on sustainability. The company uses renewable energy sources such as solar and wind power in its manufacturing process, and it also uses recycled materials to reduce waste. Overall, Gotion's lithium battery cells are a reliable, high-performance choice for a range of applications. Their high energy density, long lifespan, fast charging capabilities, and focus on safety and sustainability make them an excellent option for manufacturers and consumers alike who prioritize performance, safety, and environmental responsibility.Lishen is a leading Chinese manufacturer of lithium-ion battery cells, which are used in a variety of applications including electric vehicles, energy storage systems, and mobile devices. The company was founded in 1997 and has since become a major player in the global lithium-ion battery industry. Lishen's lithium battery cells are known for their high energy density, long lifespan, and fast charging capabilities. Their batteries are designed to provide reliable and efficient power for a range of applications. They have a wide range of products including cylindrical and prismatic cells, with capacities ranging from 10Ah to 100Ah. Lishen has also focused on developing new technologies to improve battery performance and safety. They have invested heavily in research and development, and have developed new materials and manufacturing processes to improve battery performance and safety. Lishen's lithium battery cells have passed rigorous safety tests and certifications, including UL, CE, and RoHS. They are also environmentally friendly, with a focus on using recyclable materials and reducing waste in their manufacturing process. In addition to their technical advantages, Lishen has also established a global supply chain and logistics network, which allows them to provide timely delivery and support to customers around the world. Overall, Lishen's lithium battery cells are a reliable and high-performance choice for a range of applications. Their focus on safety, efficiency, and sustainability makes them an excellent option for manufacturers and consumers alike who prioritize quality and environmental responsibility.SVOLT Energy Technology Co., Ltd. is a China-based manufacturer of lithium-ion batteries for electric vehicles and energy storage systems. The company was established in 2018 and is a subsidiary of Great Wall Motors, one of China's largest automotive companies. SVOLT has quickly become a major player in the global battery market, with a focus on developing high-performance and cost-effective battery solutions. The company has invested heavily in research and development, and has developed a range of advanced technologies to improve battery performance, safety, and sustainability. SVOLT's lithium-ion batteries are known for their high energy density, fast charging capabilities, and long lifespan. They use advanced materials and manufacturing processes to improve performance and safety, and have been certified by a range of international safety standards, including UL, CE, and RoHS. In addition to their technical advantages, SVOLT's batteries are also environmentally friendly. The company has a focus on reducing waste and using recyclable materials in their manufacturing process, and has also established a closed-loop recycling system to minimize waste and reduce environmental impact. SVOLT's batteries are used in a range of applications, including electric vehicles, energy storage systems, and mobile devices. The company has established partnerships with a number of leading automotive manufacturers and energy companies, and has a global network of production and distribution facilities to ensure timely delivery and support for their customers. Overall, SVOLT Energy Technology is a leading player in the global battery market, with a focus on developing high-performance and sustainable battery solutions for a range of applications. Their commitment to innovation, safety, and environmental responsibility makes them a reliable and trusted partner for customers around the world.

Shipping & Delivery

Professinal Package

Lithium batteries are DG goods. The shipping must according to MSDS and UN38.3 regulations. Coremax lithium batteries have passed all required rules. All batteries packed with foams in a brown carton box. Then fit into wood case or wooden pallet. The packing materials provide strong protections to inside batteries. Make sure customer receive batteries in a best condition.

How to ship lithium battery packs.

1. For small lithium batteries cells and small battery packs, we can ship by air or express.
2. For heavy shipment and higher wh/ batteries, we will shipping by freight. For large order, we ship by containers.
3. Coremax provides standard shipping to most area like USA and Europe. Shipping service include DDU. DDP. Please confirm with our sales team for the latest shipping rate.

Lithium ion batteries are different from normal shipment. It requires special shipping forwarder to take care of them. You are welcome to use your shipping agent. Before that, please confirm with your agent as these are DG shipment. We provide shipping service to most area and different country. As battery weight and detail address will cause a different shipping rate. Please contact us for the exactly shipping cost on your order.
